How telematics drives equipment efficiency in construction

Construction equipment has undergone a technological transformation over the past several years, leading to significant improvements in productivity, efficiency, safety, environmental impact and more.

Everything starts with machine telematics, however. A set of technologies that serves to remotely track, monitor and optimize machinery assets, telematics has grown and evolved quite a bit over the past decade or so. Driven by a wealth of other technologies, including GPS tracking and satellite positioning, high-bandwidth internet connectivity, smart sensors, advanced imagery, advanced computation, networking and cloud computing, the potential of telematics has never been greater than it is right now.

“Things have evolved from knowing where a piece of equipment is, to knowing what that piece of equipment is doing,” said Mike Granruth, director of business development at Trimble. “That type of information empowers not only those in charge of managing equipment, but also those who manage jobsites and the business as a whole. It all ties to the concept of executing a project that is on time and on budget, and that it’s all done safely.”

Telematics can also be leveraged to automate tasks, such as geofencing.

“Geofencing allows managers to set alarms and generate alerts when a machine reaches a certain area,” said Ted Polzer, director of product and customer support for Case Construction. “Managers can even set up geofences around areas they don’t want a machine to be able to access.”

Given that functionality, geofencing can help enhance not only safety and security, but also environmental impact.

“Say there is a low marshland near a construction site,” Polzer said. “The project manager wants to remind the crew that they shouldn’t go anywhere near that. Setting up alarms and alerts based on geofencing around a sensitive area helps managers take any necessary corrective action with operators.”

As telematics continues to mature over time, it continues to improve and gain additional functionality. Telematics is beginning to encompass additional data-gathering sensors, such as how much fuel or diesel exhaust fluid (DEF) is in a machine.

Consider a piece of equipment that is left at a jobsite overnight. The crew shows up the next morning, only to discover that the equipment is low on DEF.

“With telematics, those types of needs could be picked up prior to starting the day,” Polzer said. “Having that kind of visibility into equipment is a huge time-saver.”

When construction companies save time, they also save money — and that can have an indirect, but notable, impact on society.

“We like to talk about ‘cheaper, faster, better, greener,’” Granruth said. “The construction company wins, and so does the consumer. Labor and other project costs are reduced. Roads aren’t closed as long. Taxpayer dollars are saved on public projects. And, of course, carbon footprint is reduced as a result of being more efficient.”


Telematics Leads to Greater Fuel Savings


To further reduce carbon footprint, telematics is also aiding construction companies as they attempt to reduce fuel consumption. When telematics is leveraged across all equipment in a construction fleet, millions of gallons of diesel fuel can be saved each year in North America.

“Without telematics, managers don’t have the machine visibility they need to put procedures in place and change operator behavior,” Granruth said. He’s referencing bad habits like allowing a machine to excessively idle, which is hard on an engine and aftertreatment system. Idling also wastes fuel. In fact, it is estimated that 10-30% of the fuel consumed by construction equipment is nonproductive idling. By leveraging telematics, nonproductive idling could be reduced by 10-15%, on average.

Granruth has worked with a large fleet that did even better than that. The fleet typically consumed 30,000 gallons of diesel fuel per week. By better managing idle time, the fleet has been saving around 6,000 gallons of fuel per week (20%). Assuming a price of $4.18 per gallon, that equates to over $25,000 saved per week. Assuming 50% utilization, that equates to $650,000 in savings per year.

The reduction in carbon emissions has been just as impressive. “This fleet is saving 134,630 pounds of carbon dioxide (CO2) per week,” Granruth said. “That’s approximately 55 round-trip flights from New York to Los Angeles each week.”

Across the entire North American construction industry, the fuel saved from reducing nonproductive idling is equivalent to flying around the world 800 times. The data is clear: Leveraging telematics to reduce nonproductive idling is a huge opportunity from both a financial and environmental standpoint.


Construction companies are reducing fuel consumption and carbon emissions in other ways, too. Polzer pointed to equipment utilization and jobsite efficiency.

“Once you back out all of the time a machine spends idling, a good equipment manager can start to get a handle on whether or not certain equipment is even necessary,” Polzer said. Perhaps a site could have functioned just fine with one less loader. On the other hand, maybe the excavators weren’t keeping up with the haul trucks. The equipment manager might want to add more excavators, or perhaps upgrade to larger machines.

“What you don’t want are haul trucks sitting there idling and being nonproductive,” Polzer said. “Telematics can help bring those types of things to an equipment manager’s attention.”


Maintenance & Efficiency Considerations

When equipment managers have better visibility into how their machines are running, they can also positively impact the maintenance of those machines. This, too, can produce a win-win-win result.

“Historically, preventive maintenance on equipment has been driven by engine hours,” Granruth said. “Being able to monitor that remotely allows equipment managers to be much more timely with their maintenance.”

“You can never eliminate downtime because maintenance still needs to happen,” Polzer added. “But telematics helps an equipment manager pick a good time to schedule it when the downtime will be least impactful.”

Now, however, a concept known as “predictive maintenance” represents the next frontier of machine telematics.

“Preventive is simply about scheduling routine maintenance,” Granruth said. “Predictive is about actively monitoring how the machine is performing to determine which maintenance needs to be done, and when.”


Growing Adoption of Telematics

As the benefits of machine telematics have become clear, more equipment owners are seeking to better leverage this powerful technology. But more needs to happen to ensure widespread adoption, including:

  • State and federal funding to create efficiencies and long-term return on investment
  • Incentives to drive adoption
  • Education of key stakeholders to understand value
  • Securing of needed infrastructure for the technology to work


Granruth said telematics availability and consistency are also crucial, and it’s already being addressed. All major equipment manufacturers offer some level of connectivity and telematics on new equipment now. According to Granruth, high standards for telematics data and functionality have also been put in place, helping provide a positive experience for equipment owners.

Polzer said it’s also important to make it easier for equipment managers and technicians to access and use the telematics data.

Case Construction Equipment, for example, integrates telematics data with its electronic service manuals where technicians already spend a lot of time. “Once we grouped all of that telematics data right there with the challenge they were trying to repair, our dealer technicians started using it,” Polzer said. “And once they started using it, they started asking for more.”

On the road forward, it’s helpful to speak to equipment owners about telematics in a way that resonates with them. “Equipment owners must realize that they don’t have to sacrifice productivity and profitability for the sake of sustainability,” Granruth said.

As a matter of fact, telematics can produce a win-win-win for the construction industry, society and the environment.
